Features
Product Details
Place of Origin: Shenzhen, China
Size:23.1 , 35.1 and 47.1 inch for optional
Certification: CE, RoHS
Payment & Shipping Terms
Minimum Order Quantity: 1-10PC
Price: Negotiable
Packaging Details: EPE+ Carton box
Delivery Time: sample for 5 working days, bulk order about 25-30 days
Payment Terms: T/T, PayPal
Supply Ability: 2000pcs per month
Features
●Wall mounted series is commercial grade LCD screen technology with Android OS or Windows OS. They can be used in a wide public environments,including retail, restaurants (as Digital Menu Boards), hotels,schools, hospitals, corporate.
● Support optional IR touch, Capacitive touch, printer, NFC, camera, POE, etc to meet variety of request from the market.
● Support 7*24 Hours long time playback
● FHD, Ultra High Definition UHD, 4K different Resolution are optional, Grade A, LED Backlit, Different screen diagonal 10.1", 13.3", 15.6", 21.5",28.6”...
● Metal housing have good heat dissipation effect and tempered glass can protect screen effectively.
● With wall mounting bracket, support portrait or landscape installation
*Perfect for Retail Display
Incredibly sleek, stylish and slim yet extremely visible with 350nits display, designed to stand out in busy retail and commercial environments.
*Ultra Slim design & Black Bezel
Featuring an ultra slim profile and bezel, the square screen is perfect for a range of retail locations to suit bespoke builds and unique designs.
*Plug & Play (USB) or Cloud CMS Connected
Content can be updated easily via USB with the built-in Media Player or upgrade to a Cloud Connected Media player to schedule content and schedules remotely.
*Lightweight & Easy Installation
Complete with a hanging kit and bracket, the screen can be installed in a matter of minutes hassle free.
*24/7 Commercial Grade
As they are designed for the retail spaces these screens are commercially graded to run constantly 24/7.
Specification:
| ModeL NO. | BTS-AD231 | BTS-AD351 | BTS-AD471 | |
| LCD | LCD size | 23.1" | 35.1" ADS | 47.1" |
| Screen Qty. | Single Side | Single Side | Single Side | |
| Unit Size (mm) | 597.4*60.4*14.5 (L*W*H) | 891.6*60.4*15.8 (L*W*H) | 1211.2*67.5*22.8 (L*W*H) | |
| Unit Weight | 0.64kg | 1.8kg | 2.72+0.02kg | |
| Resolution | 1920x158 | 2880x158 | 3840*160 | |
| Brightness | 500cd/m2 | 400cd/m2 | 500cd/m2 | |
| Contrast | 3000:1 | 3000:1 | 1000:1 | |
| AA area/ Ratio | 585.6（H)x 48.19 mm(V) | 878.4(H) x 48.19 mm(V) | 1197.2（H)x 50.7 mm(V) | |
| View Angle | (Up/Down/Left/Right): 89°/89°/89°/89° | |||
| Aspect Ratio | ＞3:1（H:V） | ＞3:1（H:V） | ＞3:1(W:H) | |
| OS | OS/CPU | Android5.1/ S500 A40 | Android5.1/ S700 | Android5.1/ S700 |
| RAM/FLASH | 1G/8G | 2G/8G | ||
| Network | WIFI | 802.11b/g/n | Dual band 2.4G WIFI/ 5G WIFI | |
| Ethernet | 10M/100M | 100M | ||
| Bluetooth | BT4.0 | BT4.2 | ||
| Port | HDMI IN | 0 | 1 | 1 |
| Android HDMI-IN toggle | 0 | 1 | 1 | |
| Mini USB | 2 | 1 | USB OTG | |
| Mini RJ45 | N/A | 1 | 1 | |
| Card slot | 1 | 1 x PUSH-PUSH TF card slot | 1 x PUSH-PUSH TF card slot | |
| Type-C(DC IN) | 1 | 1 | 1 | |
| Media | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 1080p | ||
| Audio format | MP3/WMA/AAC etc. | |||
| Picture format | JPG、BMP、PNG、GIF etc and max up to 4096*4096 resolution | |||
| Design | Color | Full black or Customization | ||
| Shell Material | Metal | |||
| Installation | Wall Mounting | |||
| Others | Oper. Temp. | -10℃ ~50℃ | ||
| Storage Temp. | -20℃ ~60℃ | |||
| Working life | 50000hrs | |||
| Power | 20W, AC charger（12V/2A） | 24W, AC charger（12V/2A） | 35W, AC charger（12V/2A~~5A） | |
| Size | Packing Size | 663x463x165mm | 960x320x155mm | 1280x400x150 |
| Carton Size | N/A | N/A | 1280x400x150 | |
